TIVAR™ 88-2 ESD UHMW-PE electro static dissipative shapes prevent the build-up of electrical charges in dusty or volatile environments. As a premium ESD grade that offers low moisture absorption, the lowest coefficient of friction of all TIVAR™ 88 grades and excellent chemical resistance, TIVAR™ 88-2 ESD UHMW-PE components can be fabricated and welded for any application that requires a seamless drop-in liner, a framed-in liner, or a replacement liner. For these reasons, this UV stabilized grade is considered the material of choice for the lining of storage and transport containers, hoppers, chutes, tubes, bunkers, conveyors, vibratory pans and stand pipes. Furthermore, TIVAR™ 88-2 ESD UHMW-PE liners are available in kits and can be self-installed or professionally-installed through our extensive network of global SystemTIVAR™ Engineering partners.
PROPERTIES
Electro static dissipative
Low moisture absorption
Lowest coefficient of friction of all TIVAR™ 88 grades
Excellent chemical resistance
Thermal Properties
Property
Value
Heat Deflection Temperature at 1.8MPa (264 psi) (ºC)
Continuous allowable service temperature in air
80
Mechanical Properties
Property
Value
Tensile Strength (MPa)
Tensile Modulus of Elasticity (MPa)
Compressive stress at 1% nominal strain (MPa)
Compressive stress at 2% nominal strain (MPa)
Compressive stress at 5% nominal strain (MPa)
Flexural Strength (MPa)
Charpy Impact Notched (kJ/m²)
Chemical Properties
Property
Value
Hot Water / Steam
Limited
Acids, Weak
Acceptable
Acids, Strong (pH 1-3)
Acceptable
Alkalies, Weak
Acceptable
Alkalies, Strong (pH 11-14)
Acceptable
Hydrocarbons - Aromatic
Acceptable
Hydrocarbons - Aliphatic
Acceptable
Ketones, Esters
Acceptable
Chlorinated Solvents
Acceptable
Alcohols
Acceptable
Inorganic Salt Solutions
Acceptable
Electrical Properties
Property
Value
Dielectric Strength (kV/mm)
Certification Properties
Property
Value
FDA
Not compliant
European Food Approval
Not compliant
NSF
Not compliant
3A-SSI
Not compliant
Canada AG
USDA
Not compliant
Flammability (UL Rating)
HB
Medical use
Miscellaneous Properties
Property
Value
Base Material
UHMW-PE
Brand Family
Colors
Black Blue
Density (g/cm3)
Water Absorption after 24 hrs immersion in water (%)
